Gopal Forge Industries™ manufactures Aluminium 7075 Flanges for applications where high strength, low weight and dependable dimensional accuracy are important. Aluminium 7075 is a high-strength aluminium alloy known for its excellent strength-to-weight ratio, making it suitable for demanding engineering environments. Our flange solutions can be produced in configurations suited to different piping and equipment requirements, including applications involving pipe fittings and industrial piping solutions. Attention to machining accuracy, flange dimensions, surface finish and material consistency helps ensure reliable installation and service performance.
Aluminium 7075 Flanges, Aluminium 7075 Flanges Manufacturers, Aluminium 7075 Flanges Suppliers, Aluminium 7075 Flanges Stockists, Aluminium 7075 Flanges Exporters
As Aluminium 7075 Flanges exporters, Gopal Forge Industries™ supports customers requiring engineered flange components for domestic and international industrial projects. Export requirements can vary according to application, drawing, standard, dimensions and documentation, so product preparation should be aligned with the purchaser's technical specification. Aluminium 7075 offers a useful combination of strength and reduced weight compared with many conventional metallic materials. These characteristics make the alloy attractive for specialized equipment, engineering assemblies and piping-related applications where weight management is an important consideration.
Gopal Forge Industries™ supplies Aluminium 7075 Flanges for engineering, fabrication and industrial requirements where material selection and dimensional consistency matter. Depending on the project, flanges may be required in different sizes, pressure classes, facing arrangements, bore dimensions and connection configurations. Clear technical communication helps ensure the selected flange matches the mating pipe or equipment. Our product range can complement conventional components such as buttweld fittings, while material-specific requirements should always be confirmed against the applicable design standard and operating conditions.
As Aluminium 7075 Flanges stockists, Gopal Forge Industries™ can support procurement requirements where customers need access to commonly requested flange configurations and sizes. Availability can depend on dimensions, specification, quantity and current production or inventory schedules. Aluminium 7075 is particularly useful when engineers need a strong yet comparatively lightweight material for specialized assemblies. For projects combining aluminium components with carbon steel elbow or stainless steel elbow connections, engineers should also consider galvanic compatibility, insulation, temperature and service-environment requirements before installation.
Gopal Forge Industries™ provides Aluminium 7075 Flanges for industrial applications requiring a practical balance between mechanical strength, weight and machinability. Typical areas of interest include engineering equipment, lightweight assemblies, transportation-related systems, specialized fabrication and selected piping applications. The alloy's high strength makes it valuable where reducing component weight without moving to a lower-strength material is a priority. Correct flange selection should consider operating pressure, temperature, fluid compatibility, bolt loading, gasket selection, dimensional standards and the overall requirements of the industrial piping solutions being designed.
Aluminium 7075 Flanges Manufacturers in India, Aluminium 7075 Flanges Suppliers in India, Aluminium 7075 Flanges Stockists in India, Aluminium 7075 Flanges Exporters in India
Aluminium 7075 Flanges Specification
| Product Name |
Aluminium 7075 Flanges |
| Material |
Aluminium Alloy 7075 |
| Material Grades |
7075-T6, 7075-T651 |
| Flange Types |
Weld Neck, Slip-On, Blind, Threaded, Plate, Socket Weld, Lap Joint |
| Available Sizes |
Various sizes as per standard or customer requirements |
| Standards |
ASME, ANSI, DIN, EN, BS, JIS and customer specifications |
| Pressure Ratings |
As per applicable standard, size, design and project requirements |
| Dimensions |
OD, ID, Bore Diameter, Thickness, Bolt Hole Diameter, Bolt Circle Diameter |
| Manufacturing Process |
Forged, Rolled, Machined and Custom Fabricated |
| Surface Finish |
Machined, Mill Finish or Customer-Specified Finish |
| Key Properties |
High Strength, Lightweight, Good Machinability and Excellent Strength-to-Weight Ratio |
| Applications |
Aerospace Equipment, Industrial Machinery, Mechanical Engineering, Lightweight Piping Systems, Equipment Connections and Fabrication Projects |
Aluminium 7075 Flanges Chemical Composition
| (Al) |
(Zn) |
(Mg) |
(Cu) |
(Cr) |
(Fe) |
(Si) |
(Mn) |
(Ti) |
Other Elements |
| Balance |
5.1 – 6.1% |
2.1 – 2.9% |
1.2 – 2.0% |
0.18 – 0.28% |
0.50% max |
0.40% max |
0.30% max |
0.20% max |
0.05% max each; 0.15% max total |
Aluminium 7075 Flanges Mechanical Properties
| Tensile Strength |
Yield Strength |
Elongation |
Elastic Modulus |
Shear Modulus |
Poisson's Ratio |
Density |
Hardness |
| ≥ 572 MPa |
≥ 503 MPa |
≥ 11% |
71.7 GPa |
26.9 GPa |
0.33 |
2.81 g/cm³ |
150 HB approx. |
COMPANY CATALOGUE
Download Our Product Catalogue
Explore our complete range of products, specifications,
materials, manufacturing capabilities and technical
information in our latest product catalogue.
Related Products
FAQ's
Aluminium 7075 Flanges are high-strength aluminium alloy pipe flanges manufactured from Aluminium 7075. They are known for their excellent strength-to-weight ratio, good machinability, and lightweight construction, making them suitable for demanding engineering and industrial applications.
Common Aluminium 7075 flange types include:
- Weld Neck Flanges
- Slip-On Flanges
- Blind Flanges
- Threaded Flanges
- Plate Flanges
- Socket Weld Flanges
- Lap Joint Flanges
Aluminium 7075 Flanges can be manufactured according to applicable standards such as ASME B16.5, ASME B16.47, EN 1092-1, DIN, BS, and JIS. Pressure ratings may include Class 150, Class 300, Class 600, PN6, PN10, PN16, PN25, and PN40, subject to flange size, design, temperature, material condition, and applicable engineering requirements.
Aluminium 7075 Flanges offer high mechanical strength with low weight, along with good machinability and an excellent strength-to-weight ratio. These properties make them suitable for applications where weight reduction and high structural performance are important.
Aluminium 7075 Flanges are commonly used in aerospace-related equipment, industrial machinery, mechanical engineering, lightweight piping systems, equipment connections, fabrication components, and specialized engineering projects where high strength and lightweight construction are required.
Application of Aluminium 7075 Flanges
Latest Price List of Aluminium 7075 Flanges
The latest price of Aluminium 7075 Flanges generally varies according to flange size, thickness, standard, machining complexity, quantity, surface finish, testing requirements and raw-material market conditions. Small standard configurations may have more predictable market pricing, while large-diameter or fully customized flanges can command a higher industrial rate because of additional material consumption and machining time. For an accurate current quotation, buyers should share size, specification, quantity, drawing and required delivery schedule with Gopal Forge Industries™.
